SHACMAN H3000 8×4 Cargo Truck

Product Description:

As a benchmark model in the engineering transportation sector, the Shacman H3000 8×4 380hp Tipper Truck stands out for its exceptional performance and reliable quality, making it the top choice for heavy-duty applications in mining, infrastructure, and other demanding environments. Equipped with a high-efficiency, fuel-efficient 380-horsepower engine and advanced powertrain technology, the Shacman H3000 8×4 380hp Tipper Truck delivers powerful performance while achieving a balance between low fuel consumption and low emissions, significantly reducing operational costs for users.

inquiry now add to cart

Specifications

Driver position		Left Hand
Driving type		8*4
Wheelbase/(mm)		1800+3575+1400
Max. Speed/(km/h)		75km/h
Engine	Brand	WEICHAI
	Model	WP10.375E50
	Emission Standard	EURO V
	Rated output power/（PS）	375
	Displacement(L)	9.726L
Transmission	Brand	FAST
	Model	10JSD180T-B-QH50
Front axle	Brand	HANDE
	Model	MAN 9.5T
Rear axle	Brand	HANDE
	Model	16T MAN double reduction driving axle Speed ratio: 5.262
Clutch		￠430 diaphragm clutch
Steering		ZF technology
Frame		850x300(8+7)
Suspension		Front and rear multi-leaf spring four main flims+four horse riding
Fuel tank		400L Aluminum alloy
Wheels and tires		12.00R20
Brakes		Running brake:Dual circuit compressed air brake
		Parking brake:Air discharging with spring control
		Auxiliary brake:Engine exhaust brake
Cabin		Air main seat, four-point air suspension cab, electronically controlled automatic constant temperature air conditioner, electric window shaker, manual flip, ordinary air filter, ordinary 90 saddle, flat mounting plate, metal bumper, hinged upper carPedals, split fenders, 165Ah maintenance battery, SHACMAN logo, full English logo
Upbody		740023001500

Inquiry Now

Product Name:SHACMAN H3000 8×4 Cargo Truck
