Windmill Blade Transport Adaptor Semi Trailer

Product Description:

Designed according to the width of the blades and transportation regulations, typically between 3.5 meters and 4.5 meters. The height of the windmill blade transport adaptor can be adjusted to adapt to different transportation conditions, ensuring the stability of the blades during transportation. We provide a variety of configuration options, which can be customized according to the specific needs of customers to meet the requirements of different projects.

inquiry now add to cart

Specifications

Dimension(Optional)	Axle No.	Rated Load (kg)	Tire No.		Tire Size
Dimension Made by Customer Machine Size, Standard Length is 13500mm (contact supplier for more)	1	20	4		825R20 1000R20 1100R20 1200R20 12R22.5 (Other Size / Single Super Tire Contact with Supplier)
	2	40	8
	3	60	12
	4	80	16
	5	100	20
Manufacture	Qingdao Eleph Industry & Trade Co., Ltd
Wheel Base (mm)	1310
leaf-spring Pcs	10
Axle	13/16/18 T
Suspension	Heavy Duty Mechanic Suspension with Leaf Springs
Main Beam Material	Q345B manganese plates, automatic submerged arc welded
Brake System	Dual line braking system with automatic braking system/chambers
Brake Air Chamber	Double Model
Kingpin	2' or 3.5' Interchangeable
Landing gear	28T loading capacity with 80T static lifting capacity.
Platform	4-6 mm diamond steel plate
Brake System	Dual Lines Braking System With Automatic Air Chambers
Brake Air Chamber	Four double and two single chamber
Electrical System	24V, 7core socket, lights according to European standards.
Mainbeam Size	Upper plate			14mm
	Lower plate			16mm
	Mid Web			8 mm
	Height			500-520mm
Tool Box	1 box of standard tools
Spare tire carrier	2 sets
Color and Logo	Depends on the buyer's requirement.
Pin Height	According to the height of the tractor saddle.
Painting	Three coats painting; Any color will be available

Inquiry Now

Product Name:Windmill Blade Transport Adaptor Semi Trailer
