SINOTRUK HOWO 4×2 Tow Truck
Product Description:
The HOWO Wrecker Towing Truck is euipped with a range of advanced features that make it ideal for handling a wide vaniety of chalenging towing situationsWith its robust chasis and powerful engine, he HOW0 Wrecker Towing Truck provides the necesary strenath and puling capacity to tow even the heaviest ovehicles, The truck's hydraulic system enables it to lift and tow vehicles with ease,while its advanced suspension system ensures a smooth and stable ride.
Equipped with a range of advanced safty features,the HOWO Wrecker Towing Truck is enineered to provide a safe and secure towing experience, ts adyancedbraking system, for example, helps to prevent acidents during towing, while its powerful ights and warning signals ensure that other drivers on the road araware of its presence.
Specifications
Driving Type | Left / Right Hand Driving | |
Cabin | 2080 Cabin ( Berth can be optional) | |
Engine | Power | 120HP |
Emission | Diesel EURO III, IV, V | |
Transmission | MANUAL 6F | |
Steering | hydraulic steering with power assistance | |
Axle | Design and produce by SINOTRUK | |
Front/ Rear Axle | 2.0+4.2 | |
Wheelbase | 4200 | |
Oil tank | 120L | |
Tyres | 8.25R16 | |
Deck | ||
Rated holding capacity (kg) | 9990 | |
Maximum lifting weight (kg) | 2500 | |
Fully extended maximum lift capability (kg) | 1500 | |
Effective length of the bracket arm | 1650(mm) | |
Retracting stroke of the bracket arm | 1350(mm) | |
Upper inclination of the bracket arm | 11(°) | |
Lower inclination of the bracket arm | -8(°) | |
Minimum inclination when the plate is extended backwards (°) | 8 | |
Maximum load-carrying capacity of the plate mechanism (kg) | 4000 | |
Dimensions of the plate mechanism (mm) | 6400×2500 | |
Height of compartment floor above ground (mm) | 1158 | |
Retracting stroke of plate (mm) | 3000 | |
Maximum tension of winch (kg) | 4000 | |
Maximum tension of winch (kg) | 10 | |
Length of steel wire rope (mm) | 20 | |
Minimum linear speed of steel wire rope (m/min) | 4 |
