SINOTRUK HOWO 4×2 Asphalt Distribution Truck

Product Description:

SINOTRUK HOWO 4×2 Asphalt Distribution Truck is a heavy-duty vehicle that is ideal for construction projects requiring the distribution of hot mix asphalt. With its sturdy construction, this truck is designed to withstand the tough conditions of road construction work.The truck's interior is equipped with advanced technology that makes it easy to operate and comfortable to use, even during long hours on the job.

inquiry now add to cart

Specifications

Brand	HOWO 4*2
Cab	Power steering
Vehicle Description
Overall dimensions(mm)	735024002800
Curb weight(vehicle) (kg)	3,990
Loading capacity (kg)	6,000
Max speed (Km/h)	95-120
Engine
Mode	YN4102QBZL
Type	Diesel, 4-cylinder in line with water cooling, turbo-charging
Max. power/rotated speed	116HP
Displacement(ML)	4216
Emission level	Euro 3 EGR
Chassis Description
Wheel base	3800
Front axle	2.4T
Rear axle	4.2T
Gear box	6-speed
Brake system	Air braking
Operation control system	Power Steering
Electric system	24V
Tyres	7.50R16
Asphalt / Bitumen spraying system
Capacity of tank body:	6000Liters Thickness of tank body: 4mm Q235 carbon steel. 80mm rock wool insulation material. Outside cover 1mm Matt stainless steel
Bitumen pump	QGB680,High viscosity asphalt pump, 680 litres / min.
Hydraulic system	By manual reversing valve; asphalt pump hydraulic drive motor model 05-110-BD31; hydraulic pump model CBQ550-L;
spray width	4.5 meters; 34 intelligent asphalt nozzles.
control mode	after operation platform operation box control;
heating way	burner (Italy G20) and heat conduction oil automatic heating;
gasoline engine	6 kw

Inquiry Now

Product Name:SINOTRUK HOWO 4×2 Asphalt Distribution Truck
