SINOTRUK HOWO TX 6×4 Cargo Truck

Product Description:

HOWO TX 6X4 dump truck is highly reliable and durable due to its solid and rugged designs aiming at powerful performances, it can tackle any tasks that a heavy haulage job can expect, which makes it the best choice for overseas engineering and mining projects under the rough roads of Africa and other regions.

inquiry now add to cart

Specifications

Cabin	TX-F Driving cab, with one sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, air conditioner
Engine	Make: WEICHAI, Diesel 4-stroke direct injection diesel engine Engine model: WP12.400E201/WP10.380E22, Euro 2, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling. Displacement: 9.726 L
Transmission	HW19710, 10F & 2R, with HW50 PTO Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
Steering	BOSCH power steering, hydraulic steering with power assistance
Front Axle	VGD95, 1x 9,000 KGS, Steering with double T-cross section beam
Rear Axle	MCP16ZG, 2x16,000 KGS, Ratio 5.26, pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles.
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Chassis	Frame: U-profile parallel ladder frame with section of (8+8/300)mm, and reinforced sub-frame all cold riveted cross members Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer
Brake	Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake
Electrics	Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Fuel Tank	400L
Tires	12.00R20/13R22.5/12R22.5 Tires, 10+1 Pics.
Color	Optional
Overall Dimension	8500×2550×3600 mm
Box Dimension	580023001500 mm, 20CBM Thickness: Floor 8 mm, Side 6 mm Front or middle Hydraulic Lifting System
