SHACMAN 4×2 Light Dump Truck | L3000 Urban Tipper

SHACMAN X9 4×2 Light Dump Truck

Product Description:

Brand: SHACMAN X9

Model: Dump Truck

Drive Type: 4×2

Wheelbase: 3400 mm

ENGINE: YC4E160-33

Emission Standard: Euro II

Output Power: 118 kW / 160 HP @ 2600 r/min

Application: Infrastructure construction, agricultural transport, municipal maintenance

inquiry now add to cart

Product Details

SHACMAN X9 4×2 Dump Truck – Model SX3183F2Y16J3410 | 3400mm Wheelbase | 160HP Euro II | 18T GVW

The SHACMAN X9 is a rugged, high-performance 4×2 dump truck built for heavy-duty material hauling in construction, mining, infrastructure, and municipal projects. This model (SX3183F2Y16J3410) is powered by a reliable Yuchai Euro II engine offering an excellent balance of power, fuel efficiency, and low maintenance costs — ideal for markets where fuel quality varies and repair facilities are basic.

Why Choose This SHACMAN X9?

Proven Yuchai Euro II engine – Simple mechanical injection, no complex electronics, runs on lower‑grade diesel, easy to service anywhere.

3400mm wheelbase – Offers excellent stability for 3.6m cargo body while remaining maneuverable on narrow sites.

Heavy‑duty rear axle (10T) and double‑layer frame – Built to handle 18T GVW with confidence.

FAST 8‑speed transmission – Reliable and widely supported globally.

Half‑row cab with sleeper – Provides driver comfort and a rest area for longer hauls.

Fully customizable – Cargo box dimensions, engine power (up to 200HP), LHD/RHD, and more can be tailored to your market.

Typical Applications: Construction site hauling, mining shuttle, road building, municipal waste management, agricultural transport, infrastructure projects.

Get a Custom Quote – Contact us with your required cargo box size, preferred emission standard, and any special modifications. We will provide a tailored solution and competitive price.

Other Model:

Specifications

Model		SX3183F2Y16J3410
Driving type		4*2
Curb Weight（kg）		7000
GVW（kg）		≦18000
Overall Dimensionmm(L×W×H)		6000×2300×2700
Wheelbase(mm)		3400
Engine	Brand	Yuchai
	Model	YC4E160-33
	Emission Standard	Euro Ⅱ
	Output power	118kW/160HP
	Rated speed（r/min）	2600
	Max.Torque	520N.m/1300-1700
	Displacement(L)	4.257L
Transmission	Brand	FAST
	Model	8JS85TF-C+QD40L
Front axle		3.2t
Rear axle		10t/6.83
Frame(mm)		800x250/7+4
Suspension		9/11+8 front 9 layers/rear 11+8 layers
Fuel tank		200L iron tank
Wheels and tires		10.00R20/18PR
Cabin	X9/2120 with bed cab, Mechanical main seat, fixed auxiliary seat, front fixed rear mechanical suspension, seat belt latch alarm (main driver), central lock (1 central key +2 mechanical keys), power Windows, 4.3 inch TFT instrument combination, manual air conditioning, radio and cassette player, halogen headlights, ordinary steering wheel, rod mirror, manual flip, sunshade, secondary step, standard bumper, S Q Logo, SHACMAN logo, X9 logo, English or English logo
Others	100Ah maintenance-free battery, attached single-stage air filter (with safety filter element and cyclone), exhaust auxiliary brake, spare tire, iron air reservoir
Cargo body	36002300800, base 4 sides 3, medium

Inquiry Now

Product Name:SHACMAN X9 4×2 Light Dump Truck
