XCMG QY50K5D Truck Crane

Product Description:

The XCMG QY50K5D Truck Crane is equipped with a powerful engine and a nine-speed transmission from DaTong. It features a dual-reduction axle and high-capacity tires. The golden transmission system maximizes power performance while maintaining a high level of fuel economy. The 320L large aluminum fuel tank has strong corrosion resistance and a long range.

inquiry now add to cart

Specifications

Description		Unit	Parameter value
Overall length		mm	13930
Overall width		mm	2780
Overall Height		mm	3630
Axle base	1st ,2nd axle	mm	1470
	2nd ,3rd axle		4300
	3rd ,4th axle		1350
Wheel Base		mm	2304+2075
Front overhang/rear overhang		mm	2389/2064
Front extension/rear extension		mm	2131/226
Total vehicle mass in travel configuration		kg	42200
Axle load	Front axle	kg	16200
	Rear axle		26000
Engine rated power		kw/(r/min)	276/2200
Engine rated torque		N.m/(r/min)	1500/1300-1600
Max. travel speed		km/h	85
Min. steady travel speed		km/h	2~3
Min. turning diameter		m	24
Min. ground clearance		mm	327
Max. grade ability		%	42
Approach angle		°	19
Departure angle		°	15

Inquiry Now

Product Name:XCMG QY50K5D Truck Crane
