XCMG XC7-SR10 Skid-Steerloader

Product Description:

The XCMG XC7-SR10 represents the next evolution in XCMG's skid steer loader lineup. It is engineered with a focus on performance, operator comfort, and versatile functionality, making it a competitive machine for a wide range of compact applications.

inquiry now add to cart

Specifications

Description		Unit	XC7-SR10
Rated load		kg	1080
Tipping load		kg	2160
Operating weight		kg	3450	3700	3650
Maximum breakout force		kN	22
Engine	Manufacturer		YANMAR	Weichai
	Model		4TNV98T	WP4G80E231	WP4.1G82E301
	Rated power	Hp/kw	82.2/61.3	80/60	80/60
	Rated speed	rpm	2500	2300	2400
	Cooling mode		Water-cooling
Performance parameter	Operation mode		Pilot hydraulic control & multi-function electronic control
	Tire standard		12-16.5
	Maximum speed	Km/h	12.5
Maximum operating height		mm	4180
Bucket hinge pin height		mm	3205
Cabin top height		mm	1960
Maximum horizontal height of bucket bottom		mm	2997
Length without bucket		mm	2660
Length with bucket		mm	3610
Toppling angle		°	40
Maximum unloading height		mm	2450
Ground-bucket angle		°	30
Rotating angle of bucket at highest point		°	83
Unloading distance		mm	570
Wheel base		mm	1188
Departure angle		°	25
Ground clearance		mm	205
Wheel track		mm	1500
Bucket capacity (stacking height)		m³	0.6
Bucket capacity (tiling)		m³	0.47
Diesel tank capacity		L	95
Capacity of hydraulic oil tank		L	70
